Hubbell Wiring Device-Kellems HBL420B5W

The HUBBELL IEC Pin and Sleeve Inlet is an electrical inlet rated for 20A and 600V AC, suitable for use in industrial settings. Rated for 20A and 600V AC, this three-phase device features a flanged design with screw terminal wire connections, supporting wire sizes from #14 AWG to #10 AWG. Constructed with Zytel 101 nylon housing and thermoset polyester contact carrier; rated IP67 for protection against water ingress. It is suitable for demanding environments requiring moisture resistance and reliable performance.Key Features of the HUBBELL IEC Pin and Sleeve Inlet: Current/Voltage Rating: 20 A, 600V AC; three-phase configurationIP67 rated enclosure (omit "Watertight Construction" as a heading)Material: Housing made from Zytel 101 nylon; gasket material is neopreneCord Size Compatibility: Accepts #14 to #10 AWG wires via pressure terminal screwsRated operating temperature range: -40°C to 75°C (continuous)Flange Type: Flanged mounting with face diameter of 2.11 in and flange diameter of 2.72 inGrounding Style: IEC grounding; shrouded design per IEC standard requirementsStandards Compliance: CSA Certified (File LR280C), UL Listed (File E146032), classified under IEC 60309-1 & -2 standardsHorsepower Rating: Rated up to 10 hp applications; switch rated for current interrupting at full load
