Limit Switch - Heavy Duty, Rotary, DPDT, Zinc Die Cast, IP67-NEMA Rated LSA7L

The Honeywell Heavy Duty Limit Switch from the LSA Series is a rotary-style, momentary-action switch suitable for surface mounting. It features a zinc die cast body with no lever actuator included and utilizes screw terminals for electrical connection. The unit includes 2 NC and 2 NO contacts (DPDT), rated for operation up to 10A at 600VAC or up to 10A at 250VDC. Its construction is with materials rated as corrosion-, with ingress protection rated at IP65/66/67 and NEMA enclosure types 1, 3, 4, 4X, 6, 6P, 12, and 13. Key Features: - Actuator Style: Rotary head without lever; side-mounted - Contact Configuration: DPDT (2NC/2NO) - Electrical Ratings: Up to 10A at 600VAC / up to 10A at 250VDC - Body Material: Zinc die cast; standard style - Mounting: Surface mount with two diagonal holes (0.20 in diameter); spacing of approximately 60 mm x 30 mm center-to-center - Movement & Travel: Operates CW/CCW; differential travel of seven degrees; pretravel fifteen degrees; overtravel sixty degrees - Operating Force/Torque: Requires maximum operating force of four in-lb - Temperature Range: Operates between ten degrees F and two hundred fifty degrees F - Protection Ratings: IP65/IP66/IP67; NEMA types as listed above - Certifications: CCC, CE, CSA, UL
