Locking Connector, 20 A, 125V AC, Single Phase, 2 Pole, Screw Terminals, Black HBL23001HGB

The HUBBELL 20A Hospital Locking Plug is a locking connector intended for use in hospital-grade applications. It includes a nylon housing and insulated body; rated for use in indoor dry locations. The plug supports 2-pole, 3-wire grounding configurations; rated at 125V AC and 20A.Key Features of the HUBBELL - 20A Hospital Locking Plug: Amperage/Voltage Rating: Rated for 20 A at 125V AC single phaseConductor Range: Accepts #14 AWG to #12 AWG wire sizesCord Size Compatibility: Supports cords with diameters from 0.320 in to 0.660 inHousing Material: Nylon composite housingContact Material: Bronze contacts molded into the nose for damage resistanceCable Retention: Mechanical cord grips provide strain reliefConnection Type: Pressure terminal screws (screw terminals) for wiring connectionTemperature Rating: Operates continuously from -40°C (w/o impact) up to +75°CNEMA Configuration: Non-NEMA; straight connection orientation; grounded designUL Listed and UL94 HB flammability rated; IP20 ingress protection level
