Hubbell Wiring Device-Kellems HBL520R9W

The HUBBELL IEC Pin and Sleeve Receptacle, 20A, 208V is a watertight electrical device rated for use with 20A, 120/208V AC single phase applications. This receptacle features a rugged housing made from Zytel 101 nylon and is constructed to operate within the specified ratings. It accommodates wire sizes from #14 AWG to #10 AWG and supports straight connection orientation with pressure terminal screws for secure wiring.Key Features of the HUBBELL IEC Pin and Sleeve Receptacle: Current/Voltage Rating: Rated for 20 amps at 120/208V AC single phaseWatertight Construction: IP67 ingress protection with neoprene gasket; suitable for wet environmentsMaterial: Housing, body, and flange constructed from Zytel 101 nylon ; retainer made of high-impact thermosetCord Size Compatibility: Accepts cord sizes ranging from #14 AWG to #10 AWG (maximum wire size up to 8 AWG)Connection Type: Connection using pressure terminal screwsFlammability & Temperature Ratings: UL 94 HB or better flammability rating; operating temperature range -40°C to +75°CResistance Properties: Materials are , impact , and UV stabilizedStandards Compliance: CSA Standard C22.2 No.182.1; UL Classified/IEC 60309-1/-2; UL Listed File E146032Design Features: Color coded split sleeves; shrouded design with spring-loaded cap for added protection
