Hubbell Wiring Device-Kellems M4100R12

The HUBBELL Pin and Sleeve Receptacle is a 100A, 125/250V AC electrical connector suitable for industrial applications. It features a watertight, corrosion- construction with a yellow housing and nickel-plated solid brass pins to support reliable connections in demanding conditions. The receptacle is grounded, shrouded, and equipped with a spring-loaded cap for added protection against moisture and impact.Key Features of the HUBBELL Pin & Sleeve Receptacle: Current Rating: Rated for 100 amps at 125/250V AC single-phase operationConstruction: Nylon body with housing; corrosion, impact, moisture, and weather resistantCord Retention: External cord clamps are includedPins: Nickel-plated solid brass pinsConnection Orientation: Straight connection using screw terminals; accepts wire sizes from 3 AWG to 1/0 AWGIngress Protection: IP67 rated for water and dust resistance; NEMA Type 4X enclosure ratingCover Design: Self-closing gasketed cover (spring-loaded cap) helps maintain watertight integrity when not in useIdentification: Color-coded yellow housing aids quick identification on siteStandards Compliance: Meets CSA C22.2 No. 0.17 & No.182.1, IEC standards, UL1682 & UL94 HB flammability requirements
