Hubbell Wiring Device-Kellems M4100C12R

The HUBBELL Pin and Sleeve Connector, 100A, 125/250V is a heavy-duty electrical connector suitable for use in marine and outdoor environments; rated IP56 for moisture resistance. This pin & sleeve connector accommodates #3 AWG to #1/0 AWG conductors, features a grounded design with four wires and three poles, and operates at up to 100 amps with a voltage rating of 125/250V AC. The housing is constructed from high-visibility nylon with PBT components for added durability in demanding conditions.Key Features of the HUBBELL Pin & Sleeve Connector: Current Rating: Rated for up to 100 A at 125/250V AC single-phase operationBody Material: nylon insulated body with PBT housing features a nylon insulated body with PBT housingContact Material: nickel-plated solid brass pinsCable Range: Accepts cable diameters from 1.065 in to 1.94 in; supports wire sizes #3 AWG to #1/0 AWGConnection Type: pressure terminal screws (screw terminals) for secure wiringIngress Protection: IP56 rated for moisture resistance; includes neoprene sealing glandsTemperature Range: Operates between -40°C (minimum) and +75°C (maximum continuous)Features: Gasketed locking ring, shrouded design, self-closing gasketed cover, color-coded housings for identificationStandards Compliance: CSA Certified LR280C; UL Classified to IEC 60309-1 / IEC 60309-2; UL E146033 listed
