Limit Switch - Plunger, Boot Seal, DPDT, Zinc Die Cast, IP66 Rated DTE6-2RN

Honeywell MICRO SWITCH DTE6 Series limit switch features a plunger actuator with boot seal, suitable for use in indoor and outdoor environments, as specified by the manufacturer. The zinc die-cast housing is coated with electrostatic epoxy coating applied to the housing. This compact, miniature-style switch features a top-mounted actuator and bottom flange mounting configuration; compact dimensions are provided above. Key Features: - Contact Form: 2NC/2NO (DPDT) - AC/DC Contact Rating: 10A at 240V - Actuator Style: Plunger, boot sealed; Actuator Length: 1.06 in - Body Material: Zinc die cast; Body Dimensions (H x W x D): 2.3 x 1.0 x 3.04 in - Mounting Style: Bottom flange; Number of Mounting Holes: 2 (0.17 in diameter), Horizontal spacing: 1.63 in - Electrical Connection: Screw terminals; Wiring Entry: 1/2 in NPT - Operating Force Range: 26 ozf to 59 ozf - Travel Parameters: Differential travel—0.06 in, Pretravel—0.11 in, Overtravel—0.13 in minimum - IP66 rated enclosure; Standards met include CSA and UL
