Qa1
Qa1 Female Rod End,RH,3-4-16 CFR12
- SKU:
- ZO-G4968826
- UPC:
- 806990002082
- MPN:
- CFR12
- Condition:
- New
- Weight:
- 0.65 LBS
- Shipping:
- Free Shipping
On Sale
Frequently bought together:
Description
Spherical Rod End, System of Measurement Inch, Bore Diameter 3/4 in, Head Outside Diameter 1 3/4 in, Head Width 0.593 in, Shank Thread Length 1 1/2 in, Shank Thread Size 3/4 In.-16, Housing Material Carbon Steel, Shank Thread Direction Right Hand, Application Light Duty, Ball Diameter 1.312 in, Ball Material Alloy Steel, Ball Material Grade 52100, Bore Diameter Tolerance +0.0025/-0.0005 in, Housing Material Finish Chrome Plated, Inner Ring Width 0.875 in, Maximum Ball Swivel 24 Degrees
View AllClose
Additional Information
Country of Origin: |
China |
Color: |
Silver |
SubCategory: |
Power Transmission |
International Shipping: |
No |
Lead Time: |
Expected to ship in 1-2 business days |
Material: |
Carbon Steel |
