Model 1224 Pipe Threading Machine with Hammer Chuck, 26092, 1-4" - 4" NPT, 120 V

The RIDGID 1224 pipe threader is a stationary power threading machine designed for high-capacity pipe and bolt fabrication. Powered by a 1.5 HP, single-phase induction motor, the 1224 pipe threading machine maintains a constant torque output for threading pipe from 1/4-inch to 4-inch diameters and rod/bolts from 1/4-inch to 2-inch diameters. The system is engineered for low-noise operation and features a two-speed gearbox to optimize performance based on the workpiece size. SPECIFICATIONS: • Nominal Pipe Capacity – ¼" - 2" (6mm - 100mm) @ 36 RPM, 2 ½" - 4“ (65mm 100mm) @ 12 RPM, 4" - 6" (100mm - 150mm) with 161 Geared Threader: • Bolt Capacity – ¼" - 2" (6mm - 50mm) - Motor Control – REVERSE/OFF/FORWARD, heavy-duty rotary type and integral foot switch - Gear Box – Two speed gear box with a 3:1 ratio - Chuck – Hammer-type with replaceable rocker action jaw inserts - Rear Centering Device – Cam action - Oiling Pump – Self-priming, gerotor type, automatic reversing, constant flow - Oiling – Through die head
