Asco EF8345G001

The ASCO EF8345G001 is a pilot-operated, 4-way/2-position solenoid valve designed for controlling the flow of air, inert gases, light oil, and water. It includes an explosion-proof, watertight coil with Class F insulation. The valve features a brass body with NBR seals and pilot-operated actuation. This model is compatible with air, inert gas, light oil, and water within 10 to 150 psi differential and up to 180°F. The valve can be mounted horizontally or vertically and includes the coil and necessary seals. Key Features: - Valve Design: 4-Way/2-Position with 2 discrete positions - Actuator Type: Single Air Pilot - Body Material: Brass - Seal Material: NBR (Buna-N) - Nominal Pipe Size: 1/4 in with 4 in centerline pipe spacing - Connection Type: NPTF inlet and outlet with NPT threads - Coil Enclosure: Explosion Proof, Watertight; Coil Insulation Class: F - Electrical Connections: 1/2 in conduit with 18 in leads; Operating Voltage: 120V AC at 60 Hz - Operating Pressure Differential: 10 to 150 psi for air, inert gas, light oil, and water - Maximum Fluid Temperature: 180°F - Orifice Diameter: 1/16 in - Valve Type: NAMUR Mount - Overall Dimensions: Height 4-11/16 in, Length 3 in, Width 2-1/16 in - Wattage: 10.1 W - Includes coil and seal - Standards: CSA, SIL, UL Listed
