1 in 304 Stainless Steel Hex Head Plug, Class 150, MNPT 40HP112N010

The ZORO SELECT - 40HP112N010 is a stainless steel hex head plug designed to close off the end of a pipe, fitting, or port. 304 Stainless Steel; corrosion resistance and temperature tolerance are inherent material properties; rated for operation within -20 to 350 °F and up to 300 psi per MSS-SP-114 Class 150. Threaded MNPT connection; intended to seal when properly torqued and sealed per standard installation practices (no pre-applied sealant). It is rated for MSS-SP-114 Class 150; maximum operating pressure 300 psi and temperature range -20 to 350 °F per MSS-SP-114 Class 150. This fitting conforms to ASTM-A-351 material standards, has threads that comply with ANSI B1.20.1, and meets MSS-SP-114 Class 150 pressure ratings. Key Features: - Material: 304 Stainless Steel- Fitting Shape: Hex Head Plug- Connection Type: Male National Pipe Thread (MNPT)- Nominal Pipe Size: 1 inch- Pressure Class: Class 150- Maximum Operating Pressure: 300 psi- Maximum Steam Pressure: 150 psi- Temperature Range: -20 Degrees to 350 Degrees F- Plug Drive Style: 3 inch Hex Head- Overall Length: 34 mm- Outside Diameter: 1 inch- No pre-applied thread sealant; apply appropriate thread sealant per standard installation practices.- Standards: ASTM-A-351; ANSI B1.20.1; MSS-SP-114 Class 150- Not Magnetic
