Asco 8215B070CSA

ASCO 8215B070CSA is a 2-way, 2-position direct-acting solenoid valve with a normally closed configuration. Constructed with an aluminum body and NBR seals, it provides fast and automated fluid control with a response time of 120 milliseconds. The valve includes a coil and is rated for operation within an ambient temperature range of 14°F to 140°F and fluid temperatures up to 125°F. Environmental rating: Indoor/Outdoor. Key Features: - Valve Design: 2-Way/2-Position with Normally Closed configuration - Valve Type: High Flow - Body Material: Aluminum - Seal Material: NBR - Orifice Diameter: 1-5/8 in - Nominal Pipe Size: 1-1/2 in - Connection Types: Inlet and Outlet NPTF threads with NPT thread type - Coil: Included with general purpose enclosure and Class F insulation - Electrical Connection: 1/2 in Conduit with 18 in Leads - Voltage: 120V AC at 50/60 Hz - Wattage: 15.4 W - Flow Coefficient (Cv): 35 - Operating Pressure Differential: 0 to 25 psi for air/inert gas and water - Ambient Temperature Range: 14°F to 140°F; Maximum Fluid Temperature: 125°F - Environmental rating: Indoor/Outdoor - Response time: 120 milliseconds - Dimensions: Overall Height 6-13/16 in; Length 5 in; Width 5-3/8 in - Standards: CSA, UL - IP Rating: IP65; NEMA Enclosure Rating: 1
