Schneider Electric LC1D12KUE

Schneider Electric TeSys Deca IEC Magnetic Contactor is a three-pole, non-reversing, electrically operated switch used to control power circuits in IEC-standard control systems. It is rated for operation within the specified voltage ranges of 100–250 V AC/DC and uses screw clamp terminals. The device includes two auxiliary contacts (1NO/1NC) and is configured as a 3-pole, 3-phase device that does not include an integrated surge suppression feature and has no enclosure. Key features - Poles: 3; Reversing: Non-Reversing - Coil Voltage: 100–250 V AC/DC - Auxiliary Contacts: 2 total (1NO/1NC) - Connection: Screw Clamp Terminals - Frame/Series: TeSys Deca (TeSys) - Rated Voltage: 690 V AC; Frequency: 50/60 Hz - Full Load Amps: Rated for applications within the specified current ratings of inductive 12 A and resistive 25 A at their respective voltages - Enclosure: The device is provided without an enclosure - IP Rating: IP20 - Dimensions: 1.77 in W × 3.03 in H × 3.38 in D; Net Weight: 0.373 kg - Standards: Complies with listed standards UL, EN/IEC 60947-4-1, and EN/IEC 60947-5-1 (compliance subject to proper installation and use) - Other: Impulse Withstand Voltage 6 kV; Non-Overlap Time 1.5 ms; Shocks 15 G (closed) / 10 G (open)
