IEC Magnetic Contactor, 1NC-1NO, 24V-60V AC-DC, 3 P, Non-Reversing, Screw Clamp LC1D25BNE

This Schneider Electric IEC Magnetic Contactor (TeSys Deca) is a 3-pole, non-reversing device rated for switching within specified electrical parameters. It is designed for operation with coil voltages between 24 and 60 V (AC/DC). It contains auxiliary contacts rated for specified electrical loads. It features an IP20 enclosure with a protective cover and is suitable for use within the specified voltage ratings and load types as per manufacturer specifications. Compatible with mounting methods such as DIN rail or plate, according to installation guidelines. - Coil voltage: Rated coil voltage: 24–60 V AC/DC - Auxiliary contacts: Included; ratings should be verified for specific applications - Main/auxiliary configuration: Configured as a non-reversing device with three poles - Terminals: Screw clamp terminals suitable within specified wire ranges - Series/standards: Conforms to applicable standards listed but does not imply certification beyond those standards - Enclosure and mounting: IP20 enclosure rating; compatible with mounting methods such as DIN rail or plate, according to installation guidelines - Maximum voltage and current: Rated for maximum voltage up to approximately 690 V AC; Full Load Amps: 25 A (Inductive), 40 A (Resistive) under standard conditions - Making capacity: Capacities are based on tested conditions but do not guarantee performance under all circumstances - Mechanical/Electrical durability: Durability figures are based on testing cycles under specific test conditions, not indicative of lifespan in all environments - Inrush/holding and loss: Power consumption figures specify typical values during operation but do not guarantee performance or safety margins - Frequency: 50/60 Hz; Standards: CCC, CSA, CSA C22.2 No 60947-4-1, DNV-GL, EAC, EN/IEC 60947-4-1, EN/IEC 60947-5-1, IEC 60335-1, KC, LROS, UKCA, UL Listed, UL 60947-4-1 - Physical size and weight: Width 1.77 in; Depth 3.62 in; Height 3.35 in; Net Weight 0.433 kg (dimensions approximate)
