Hubbell Wiring Device-Kellems BR20STI

The HUBBELL Duplex Straight Blade Receptacle is a 20A, 125V AC device intended for use in indoor, commercial environments. It features the EdgeConnectâ„¢ screwless termination system, allowing wires to be connected by simply inserting and pressing down the plunger—no tools required. This duplex receptacle supports back-wired, push-in connections and is suitable for dry locations with a tamper- design.Key Features of the HUBBELL Duplex Straight Blade Receptacle: Connection Type: Push-in, back-wired screwless termination for faster installationCurrent/Voltage Rating: Rated for 20A at 125V ACNEMA Configuration: 5-20R duplex outlet with polarized and grounded designTamper : Includes design elements intended to reduce the likelihood of unwanted object insertionContact Material: Copper alloy contacts with triple and double wipe pointsCircuit Tab: Easy access split circuit tab allows flexible wiring optionsWire Size Compatibility: Accepts wire sizes from 14 AWG to 10 AWG (3-wire)Operating Temperature Range: -40°F to 167°F; suitable for dry, indoor environmentsMounting Hardware Included; Surface mount type with single gang configurationStandards Compliance: CSA Certified (22.2 No 42 File 285), NEMA WD-6, UL Listed (UL498 File No E2186)
