Schneider Electric LC2K1210F7

The Schneider Electric IEC Magnetic Contactor is a 3-pole reversing contactor with a 110 V AC coil and screw clamp terminals. It belongs to the TeSys K family and is specified without auxiliary contacts. This IEC magnetic contactor is designed to switch power circuits for motor control and resistive loads in control panels, adhering to IEC standards for compact, modular devices. - Type: IEC Magnetic Contactor, Reversing, 3P; Frame/Series: TeSys K - Coil Voltage: 110 V AC - Terminals: Screw Clamp - Mounting: DIN Rail, Plate - Enclosure: No Enclosure; IP Rating: IP20 - Applications: The product is intended for switching applications within its rated specifications. - Maximum Voltage: Rated for operation within specified voltage ranges; Frequency: 50/60 Hz - Full Load Amps: Rated current based on typical load conditions (Inductive 12 A; Resistive 20 A) - Rated Operational Current: 12 A AC-3 up to 440 V; 20 A AC-1 up to 690 V — Rated operational currents are provided according to standard testing conditions. - Rated Making Capacity: 144 A @ 690 V (Power); 110 A @ 690 V (Signalling) — The making capacity indicates maximum tested capabilities under specific conditions. - Impedance: 3 mΩ - Impulse Withstand Voltage: 8 kV - Inrush VA: 30 VA; Hold VA: 4.5 VA - Mechanical Durability: 5 Mcycles - Net Weight: 0.39 kg - Dimensions: Width 3.54 in; Height 2.28 in; Depth 2.24 in - Ambient Operation: -25 to 50°C; Ambient Storage: -50 to 80°C - Certifications: CB Scheme; CCC; UL; CSA; EAC; CE; UKCA - Reversing: Yes; Terminal Connection Type: Screw Clamp - Maximum Operating Temperature: 122°F; Overvoltage Category: CAT III - Protective Treatment: TC IEC 60068; TC DIN 50016
