IEC Magnetic Contactor, 1NC-1NO, 120V AC, 3 P, Reversing, Screw Clamp LC2D25G7V

The IEC Magnetic Contactor is a 3-pole reversing contactor in the TeSys Deca lineup, rated for switching power circuits within specified load types. It operates with a 120 V AC coil; includes auxiliary contacts as specified. The device conforms to IEC standards applicable to this product category, uses screw clamp terminals, and is rated IP20 for enclosure protection level. It mounts on DIN rail or plate and includes a protective cover; it does not include an integrated surge suppression device and is preassembled with a reversing power busbar. It is rated for operation up to 690 V AC within specified conditions and is rated for use at frequencies of 50/60 Hz within specified parameters. Overall dimensions are width 3.54 in, height 3.35 in, and depth 3.62 in, with a net weight of 0.787 kg. - Action: Reversing - Poles: 3 - Auxiliary contacts: 2 (1NO/1NC) - Coil voltage: 120 V AC - Maximum voltage rating: Rated for operation up to 690 V AC within specified conditions - Series/contactor style: TeSys Deca, IEC - Frequency: Rated for use at frequencies of 50/60 Hz within specified parameters - Enclosure: IP20 rated for enclosure protection level - Mounting: DIN Rail, Plate - Electrical connection: Screw Clamp Terminals - Includes protective cover: Yes - Embedded surge suppressor: No - Features: Without Built-In Suppressor Module; Preassembled with Reversing Power Busbar - Rated making capacity: 450 A @ 440 V (Power Circuit); 140 A (AC Signalling); 250 A (DC Signalling) - Full load currents: 25 A inductive; 40 A resistive - Net weight: 0.787 kg - Interlocks included: Electrical Interlock, Mechanical Interlock
