IEC Magnetic Contactor, 1NC-1NO, 200V AC, 3 P, Non-Reversing, Screw Clamp LC1D50AL7

Schneider Electric IEC Magnetic Contactor, 3-pole, non-reversing, with a 200 V AC coil and 1 normally open/1 normally closed auxiliary contacts (2 auxiliary contacts total). It is an IEC-style magnetic contactor rated for switching power circuits for motor control and resistive loads, suitable for installation in control panels with standardized sizing. - Action: Non-Reversing - Poles: 3; Phase: Three - Coil Voltage: 200 V AC - Auxiliary Contacts: 2 total (1NO/1NC) - Main Contacts: 3 NO - Contactor Style: IEC - Application: Suitable for motor control and resistive load applications (see specifications). - Electrical Connection: Control Circuit: Screw Clamp Terminals; Power Circuit: EverLink BTR Screw Connectors - Includes: Power connections and protective cover as specified. - IP Rating / Enclosure: Rated at IP20; enclosure not included. - Mounting Style / Mounts On: Compatible with DIN rail or mounting plates as specified. - Dimensions: Dimensions are provided as approximate measurements based on product specifications. - Net Weight: Net weight is approximately 0.855 kg based on manufacturing data. - Rated Voltage: Rated voltage ranges are specified within the product's operational ratings (see specifications). - Series: Series designation only; does not imply performance guarantees beyond listed standards. - Reversing: Reversing function not included or supported by this model specification. - Overvoltage Category: Overvoltage category classification per standards but does not guarantee suitability under all conditions outside specified ratings. - Frequency: Frequency compatibility within standard operating ranges (see specifications). - Rated Making Capacity: Capacities are rated values based on testing conditions but do not imply continuous or guaranteed operation under all circumstances. - Rated Short-Time Withstand Current: 400 A (40°C, 10 s); 810 A (40°C, 1 s) - Mechanical Durability: 6 Mcycles - Electrical Durability: 1,100,000 to 1,450,000 cycles - Stand
