IEC Magnetic Contactor, 1NC, 24V DC, 3 P, Non-Reversing, Screw XTCE012B01TD

The Eaton XT IEC contactor is an IEC magnetic contactor configured as a 3-pole, non-reversing device with a 24 V DC coil. It features a 12 A amperage rating and 1NC auxiliary contact. The contactor features screw terminal connections; complies with applicable standards including UL Listed, CSA Certified, CE Marked; EN/IEC standards such as EN 60947 and IEC 60947; RoHS compliance; frame size B. Suitable mounting options include DIN Rail or Panel mount; enclosures available vary based on configuration. Its maximum rated operational voltage is up to 690 V AC. The device's dimensions are approximately 2.95 inches deep by 1.77 inches high by about 3 inches wide. Mechanical durability is approximately 10 million cycles; electrical durability is approximately 1 million cycles. Certifications include UL Listed, CSA Certified, CE Marked, EN 60947, IEC 60947, and RoHS. - Item: IEC Magnetic Contactor - Series: XT - Contactor Style: IEC - Reversing: No - Action: Non-Reversing - Poles: 3 - Coil Voltage: 24 V DC - Amperage Rating: 12 A - Aux Contacts: 1NC - Embedded Surge Suppressor: Yes - Electrical Connection: Screw Terminals - Frame Size: B - Mounting Style: DIN Rail, Panel - Enclosure: No Enclosure - IP Rating: IP20 - Maximum Voltage Rating: Up to 690 V AC - Certifications/Standards: UL Listed; CSA Certified; CE Marked; EN 60947; IEC 60947; RoHS - Mechanical Durability: Approximately 10,000,000 cycles - Electrical Durability: Approximately 1,000,000 cycles - Maximum Operating Temperature: 122 Degrees F - Minimum Operating Temperature: -13 Degrees F - Width/Height/Depth: 3 in x 1.77 in x 2.95 in - Includes Auxiliary Contacts: Yes - Product Name: Eaton XT IEC contactor
