IEC Magnetic Contactor, 1NC, 24V DC, 3 P, Non-Reversing, Screw XTCE007B01TD

The Eaton XT IEC contactor is a 3-pole, non-reversing IEC magnetic contactor with a 24 V DC coil. It is rated for operation at the specified current levels and includes one NC auxiliary contact. The device uses screw terminals and supports DIN Rail or Panel mounting in frame size B (XT series). It carries UL Listed and CSA Certified marks and is designed for use within the specified voltage and frequency ranges, with IP20 protection and no enclosure. Key features: - Poles: 3; Main contact configuration: 1 NC; Auxiliary contacts: 1 NC (Includes 1NC) - Coil voltage: 24 V DC - Electrical ratings: 7 A inductive, 22 A resistive (Full Load) - Durability: 10,000,000 electrical cycles; 10,000,000 mechanical cycles - Termination: Screw terminals - Mounting: DIN Rail, Panel - Frame/Series: XT series; Frame size B - Maximum voltage: 690 V AC; Frequency: 50/60 Hz - Enclosure/IP: IP20; No Enclosure - Certifications: UL Listed; CSA Certified - Temperature range: -13°F to 122°F - Dimensions: 2.95 in depth; 3.00 in height; 1.77 in width - Reversing: No (Non-Reversing)
