IEC Magnetic Contactor, 1NO, 24V DC, 3 P, Non-Reversing, Screw XTCE012B10TD

The Eaton XT IEC contactor is a 3-pole, non-reversing IEC magnetic contactor with a 24 V DC coil. It provides 1 normally open main contact and includes 1 NO auxiliary contact. It is rated for a maximum of 12 A inductive load and 22 A resistive load within specified conditions, uses screw terminals, and is compatible with DIN rail or panel mounting as per installation guidelines. This XT-series frame B device is designed for operation at voltages up to 690 V AC within specified parameters, with IP20 protection and no enclosure, and carries UL Listed, CSA Certified, IEC 60947, EN 60947, CE Marked, and RoHS certifications. - Coil voltage: 24 V DC - Action: Non-Reversing; Reversing: No - Poles: 3 - Main contact configuration: 1 NO - Auxiliary contact: Includes 1 auxiliary contact (1 NO) - Full-load amps: Inductive 12 A; Resistive 22 A - Maximum voltage rating: 690 V AC - Mounting: DIN Rail, Panel - Terminals: Screw - Enclosure: No Enclosure - IP rating: IP20 - Durability: Endurance ratings based on testing standards; actual performance may vary depending on usage conditions - Certifications/Compliances: UL Listed; CSA Certified; IEC 60947; EN 60947; CE Marked; RoHS - Series/Frame: XT; Frame Size: B - Dimensions: 3 in W x 2 in H x 3 in D - Operating temperatures: -13°F to 122°F
