Limit Switch - Heavy Duty, Rotary, SPDT, Zinc Die Cast, 10A-600VAC, IP67 LSP1A

The Honeywell Heavy Duty Limit Switch is a rotary, momentary-action switch from the LSP Series, designed with a side actuator location and no lever. It features a zinc die cast miniature body style with plug-in configuration and surface mounting capability. The unit offers 1NC/1NO (SPDT) contact form, supporting both AC (10A at 600V) and DC (10A at 250V) ratings. Its rugged housing provides resistance to corrosion and is rated for use in demanding conditions. Key features include: - Rotary head actuator style without lever; side-mounted - Contact rating: 10A at 600VAC / 10A at 250VDC - Contact form: Single-pole double-throw (1NC/1NO) - Body dimensions: Height 2.95 in, Width 1.62 in, Depth 1.75 in; overall height of assembly is 4.20 in - Zinc die cast construction is rated for corrosion resistance per manufacturer specifications - Surface mount design with two diagonal mounting holes (0.2 in diameter), spaced at 2.34 x 1.16 inches center-to-center - Movement supports clockwise/counterclockwise operation; differential travel of 3°, pretravel of 9°, overtravel of minimum 66° - Operating force up to 4 in-lb; operating temperature range from 10°F to 250°F - Electrical connection via screw terminals; wiring entry size is ^1⁄2"-14 NPT - Rated IP65/IP66/IP67 and NEMA types: 1, 3, 4, 4X, 6, 6P, 12, 13 - Certified to CCC, CE, CSA & UL standards
