Hubbell Wiring Device-Kellems Receptacle, GrnFemale, Stud.Taper Nose HBLFRSCGN

The HUBBELL Receptacle, GrnFemale, Stud.Taper Nose is a single pole, female panel mount receptacle rated for use in applications requiring up to 400A at 600V AC or 250V DC. Compatible with Series 16 devices and rated for up to 400A at 600V AC or 250V DC, this receptacle features a straight connection orientation and utilizes a threaded stud terminal connection. The housing is constructed from elastomer and is intended for installation in dry, indoor environments.Key Features of the HUBBELL Receptacle, GrnFemale, Stud.Taper Nose: Amperage/Voltage Rating: Rated for up to 400A (AC/DC) and 600V AC / 250V DCConnection Type: Threaded stud terminal with taper nose designCompatible Wire Size: Accepts #4 AWG to #4/0 AWG conductorsHousing Material: elastomer constructionNEMA Enclosure Ratings: Suitable for NEMA Types 12, 3R, and 4X enclosuresStandards Compliance: Meets ANSI/NFPA 70 (NEC), UL Listed, cUL Listed requirementsMounting Style: Panel mount with threaded thru-hole hardwarePole/Wire Configuration: Single pole device accommodating one wire per unit
