Standard 1-4” NPT Air Regulator with Gauge, 50 SCFM 7843 MED-ATD-7843

Standard 1/4” NPT Air Regulator with Gauge, 50 SCFM Pipe Size: 1/4”. Operating Temperature: 40º-120º F. Adjustment Range: 5 to 125 psig. Adjustment knob. 50 SCFM maximum. (2) 1/4” NPT gauge ports. Pressure gauge included. . Regulates air pressure of the air line. . Self-relieving style units. . Features three position non-rising knob—push to lock, pull to adjust, detach to make tamper . . T-handle also available. . Always use a filter before the regulator to protect the regulator from dirt and debris. . Pneumatic equipment that operates at higher than recommended pressure can cause excess torque, force and wear and can waste compressed air. . Operating below specified pressure can cause machines to fail to meet their design performance Specifications. . Therefore, precise air pressure control is essential to efficient operation of air powered equipment. . An air line regulator is a specialized control valve which reduces upstream supply pressure level to a specified constant downstream pressure. 7843
